XC7SHU04GV,125

Overview

The XC7SHU04GV,125 is a single inverter manufactured by Nexperia, belonging to the XC7SHU logic series. It utilizes CMOS technology and is housed in an SC-74A (SOT753) surface-mount package with five pins. The device operates within a supply voltage range of 2 V to 5.5 V and supports an extended industrial temperature range from -40 °C to +125 °C.

Feature Summary

• Provides signal inversion functionality within a compact five-pin surface-mount footprint.
• Operates across a wide supply voltage range suitable for mixed-voltage system architectures.
• Designed for high-temperature reliability with specified operation up to 125 °C.

Applications

• Signal inversion in low-power digital circuits
• Voltage level translation between different logic domains
• Clock signal conditioning in embedded systems

Procurement Notes

Verify the specific suffix GV against official Nexperia documentation to confirm the SC-74A package variant. Ensure the order quantity aligns with manufacturer minimums if applicable. Cross-reference the full part number with current datasheets to validate availability status and production lifecycle stage before finalizing procurement plans.

Selection Notes

Select this component when a single inverter is required in a minimal footprint. The wide voltage tolerance allows compatibility with both 3.3 V and 5 V logic families. Consider the thermal rating for environments exceeding standard commercial limits. Verify input/output characteristics against the specific load requirements of the target application circuit.

Part Context

This device is part of Nexperia's XC7SHU family, which focuses on ultra-low power consumption and small form factors. The series is designed to replace traditional logic gates in space-constrained portable and battery-operated devices while maintaining robust performance across varying supply voltages.

Replacement Considerations

Consult official Nexperia substitution guides for verified equivalents. Generic logic inverters may not match the specific voltage or thermal specifications. Do not assume pinout compatibility without verifying the package type against the candidate replacement part.
