XC7WT14DP,125

Overview

The XC7WT14DP,125 is a hex inverter manufactured by Nexperia, housed in an 8-lead TSSOP surface-mount package. It contains three independent inverting circuits within the specified logic family. The device operates with a supply voltage range from -500 mV to 7 V and supports a propagation delay of 11 ns. It is rated for industrial temperature conditions, functioning reliably between -40°C and +125°C. This component is classified under Logic ICs and Inverters, designed for signal inversion applications requiring standard CMOS performance characteristics.

Feature Summary

• Provides three independent inverting channels for signal processing
• Operates across a wide supply voltage range extending below ground potential
• Engineered for high-temperature reliability up to 125°C

Applications

• General-purpose digital signal inversion
• Clock signal conditioning
• Logic level translation interfaces

Procurement Notes

Verify the specific suffix 125 against the manufacturer's current datasheet to confirm tape-and-reel packaging specifications. Ensure the ordering quantity aligns with the factory pack size requirements. Confirm RoHS compliance status directly with the supplier documentation prior to finalizing procurement decisions.

Selection Notes

Select this component when a hex inverter configuration is required in a compact TSSOP-8 footprint. Consider the extended operating temperature range for environments exceeding standard commercial limits. Verify that the 11 ns propagation delay meets the timing constraints of the target circuit design.

Part Context

This part belongs to the Nexperia XC7W series of logic devices, which are designed for general-purpose digital applications. The series offers various configurations including inverters and buffers in small outline packages. The XC7WT14DP variant specifically provides the inverting function necessary for boolean logic operations in embedded systems.

Replacement Considerations

Check for direct pin-compatible alternatives within the same Nexperia logic family. Verify that any substitute maintains the identical TSSOP-8 package dimensions and electrical characteristics.
