XC9244A30C7R-G

$1.90

Description：IC REG BUCK 3V 400MA 6USPN
Series：XC9244
Mfr：Torex Semiconductor Ltd
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:5218271c98bf Category: Voltage Regulators - DC DC Switching Regulators Brand: Torex Semiconductor Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

XC9244A30C7R-G is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Torex Semiconductor Ltd. Its product description is IC REG BUCK 3V 400MA 6USPN. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for XC9244A30C7R-G

Description：IC REG BUCK 3V 400MA 6USPN
Series：XC9244
Mfr：Torex Semiconductor Ltd
Package：Tape & Reel (TR),Cut Tape (CT)
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Output Type：Fixed
Number of Outputs：1
Voltage - Input (Min)：2.3V
Voltage - Input (Max)：6V
Voltage - Output (Min/Fixed)：3V
Voltage - Output (Max)：-
Current - Output：400mA
Frequency - Switching：1.2MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：6-XFDFN
Supplier Device Package：6-USPN (1.3x1.3)

Voltage Regulators - DC DC Switching Regulators datasheet and documents for XC9244A30C7R-G

XC9244A30C7R-G

Voltage Regulators - DC DC Switching Regulators Overview

The XC9244A30C7R-G is a synchronous step-down DC/DC converter manufactured by Torex Semiconductor. It operates within an input voltage range of 2.3 V to 6 V and provides a fixed output voltage of 3 V at a maximum output current of 400 mA. The device features a switching frequency of 1.2 MHz and a typical quiescent current of 18 uA. It is housed in a USPN-6 package and supports surface mount installation. The component functions reliably across an operating temperature range from -40°C to +85°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Synchronous buck topology for efficient power conversion
Fixed 3 V output configuration
Low quiescent current operation

Voltage Regulators - DC DC Switching Regulators Applications

Battery-powered portable electronics
General purpose low voltage regulation
Embedded system power supplies

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific suffix C7R against official documentation to confirm packaging details such as reel size or tape specifications. Ensure the USPN-6 footprint matches the target PCB layout. Confirm RoHS compliance status through the manufacturer's latest environmental declaration before finalizing procurement orders.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a fixed 3 V output is required from a 2.3 V to 6 V input source. The 400 mA current capability suits moderate load applications. The 1.2 MHz frequency allows for compact external component sizing. Verify that the USPN-6 package is compatible with the assembly process and thermal requirements of the design.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the XC9244 series of synchronous step-down converters from Torex Semiconductor. The series focuses on high efficiency and low standby current for battery-operated devices. The XC9244A30C7R-G specifically denotes the 3 V output variant with the associated packaging code.
