XJCBBIAANF-10.368000

Crystals Overview

The Taitien XJCBBIAANF-10.368000 is a parallel fundamental quartz crystal designed for surface mount applications. It operates at a nominal frequency of 10.368 MHz and utilizes a 4-pin SMD package with dimensions of 1.65mm x 1.25mm x 0.3mm. Key electrical parameters include a load capacitance of 10 pF, a maximum series resistance of 150 Ω, and a frequency tolerance of ±25 ppm. The device maintains a frequency stability of 0.01% and exhibits an aging rate of 1 ppm per year. It supports a drive level of 10 µW and functions within a temperature range of -40 °C to +125 °C.

Crystals Feature Summary

• Ultra-thin ceramic surface mount package design
• High frequency stability with low aging characteristics
• Compliant with RoHS environmental standards

Crystals Applications

• Bluetooth modules
• Mobile phone systems
• Wireless LAN devices
• Office automation equipment

Crystals Procurement Notes

Verify the specific ordering suffix against official Taitien documentation to ensure correct frequency and tolerance specifications. Confirm that the selected variant matches the required load capacitance and physical package dimensions for your PCB layout. Cross-reference the part number with current manufacturer datasheets to validate compliance status and operational temperature ranges before finalizing procurement orders.

Crystals Selection Notes

Select this component when a compact surface mount footprint is required alongside stable timing performance in harsh thermal environments. The wide operating temperature range makes it suitable for industrial or automotive adjacent applications where standard commercial grade crystals might fail. Ensure circuit design accommodates the specified drive level to prevent frequency deviation or crystal damage during operation.

Crystals Part Context

This component belongs to Taitien's X3 series of miniature SMD crystals. The series is characterized by ultra-thin ceramic packages optimized for automatic assembly processes. Taitien is a recognized global manufacturer of frequency control products, providing solutions ranging from basic crystals to precision oscillators for telecommunications and consumer electronics markets.

Crystals Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify compatibility with alternative suppliers by matching critical parameters such as frequency, load capacitance, package dimensions, and mounting style.
