Product Detailed Parameters
- Description：XTAL OSC 10.0000MHZ SMD
- Series：XO5080
- Mfr：MtronPTI
- Package：Bulk
- Base Resonator：Crystal
- Type：-
- Frequency：10 MHz
- Function：-
- Output：-
- Voltage - Supply：12V
- Frequency Stability：-
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 80°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：-
- Size / Dimension：1.030" L x 1.030" W (26.16mm x 26.16mm)
- Height - Seated (Max)：0.500" (12.70mm)
- Supplier Device Package：-
Download product information
Overview
The XO5083-079SR is a surface-mount crystal oscillator manufactured by MtronPTI. It operates at a nominal frequency of 10.000000 MHz and requires a 12V power supply. The device utilizes a crystal base resonator and is designed for SMD applications. Initial accuracy specifications indicate performance within -0.1 to +0.1 ppm at 25°C with VTUNE set to +2V. The component features a seated height maximum of 0.500 inches (12.70mm).
Feature Summary
- Surface mount construction for automated assembly integration.
- High stability crystal base resonator technology.
- Compatible with 12V power supply requirements.
Applications
- Precision timing circuits requiring stable clock signals.
- Electronic systems utilizing surface mount technology.
- Applications demanding high initial frequency accuracy.
Procurement Notes
Verify the specific voltage supply requirement of 12V against your system design, as this differs from standard low-voltage oscillators. Confirm that the physical dimensions, particularly the 12.70mm seated height, fit within your enclosure constraints. Ensure compatibility with the required VTUNE control voltage if active tuning is utilized in your circuit architecture.
Selection Notes
Select this component when a 10 MHz output is strictly required alongside a 12V operating voltage. Consider the physical footprint and height limitations of your PCB layout before finalizing the choice. Evaluate whether the specified initial accuracy meets your system's timing tolerance requirements compared to other available oscillator families.
Part Context
This part belongs to the MtronPTI oscillator portfolio, which includes various crystal and ceramic resonators. The manufacturer specializes in providing custom and standard timing solutions for embedded systems. This specific model represents their surface-mount offerings designed for reliability in industrial and commercial electronic applications.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify pinout and electrical specifications carefully if considering alternative manufacturers. Cross-reference the 12V supply requirement and 10 MHz frequency with potential replacements to ensure functional equivalence.
