XO9095-014

Overview

The XO9095-014 is a high-frequency Oven-Controlled Crystal Oscillator (OCXO) manufactured by MtronPTI. It operates at a fixed frequency of 1 GHz and utilizes a sine wave output configuration. The device is designed for precision timing applications requiring exceptional stability, low phase noise, and low g-sensitivity. It functions within a standard voltage range, typically associated with 5V operation in this series, and incorporates integrated low-noise multipliers and filters to enhance signal integrity.

Feature Summary

• High-frequency performance with integrated low-noise multipliers and filters
• Exceptional frequency stability and low phase noise characteristics
• Low g-sensitivity design suitable for dynamic environments

Applications

• Radar systems
• Electronic warfare equipment
• Satellite communication terminals
• Precision test and measurement instruments

Procurement Notes

Verify the specific ordering suffix against the manufacturer's current documentation to ensure compatibility with required aging rates and control voltage specifications. Confirm that the sine wave output matches system input requirements. Cross-reference the part number with official MtronPTI datasheets to validate active status and environmental ratings before procurement.

Selection Notes

Select this component when a stable 1 GHz reference source is required for radar or satellite communications. Consider the integrated filter and multiplier architecture for simplified circuit design. Evaluate the low g-sensitivity feature if the application involves mechanical vibration or shock. Ensure the thermal management strategy supports the oven-controlled operation typical of OCXOs.

Part Context

The XO9095 series represents MtronPTI's solution for high-frequency precision timing. This model specifically addresses the need for low phase noise at 1 GHz. It is part of a broader line of frequency control solutions including crystal resonators and microwave components, targeting defense and aerospace sectors.

Replacement Considerations

Consult official MtronPTI substitution guides for direct replacements. Verify pinout compatibility and electrical parameters such as aging rate and phase noise profiles. Generic OCXOs may not match the integrated multiplier and filter architecture of this specific series.
