XR76201EL

Description：IC REG BUCK ADJ 1.5A 30QFN
Series：PowerBlox™
Mfr：MaxLinear, Inc.
Package：Tray

SKU:eb674bb4f573 Category: Voltage Regulators - DC DC Switching Regulators Brand: MaxLinear, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

XR76201EL is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists MaxLinear, Inc.. Its product description is IC REG BUCK ADJ 1.5A 30QFN. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for XR76201EL

Description：IC REG BUCK ADJ 1.5A 30QFN
Series：PowerBlox™
Mfr：MaxLinear, Inc.
Package：Tray
Function：Step-Down
Output Configuration：Positive
Topology：Buck
Output Type：Adjustable
Number of Outputs：1
Voltage - Input (Min)：3V
Voltage - Input (Max)：40V
Voltage - Output (Min/Fixed)：0.6V
Voltage - Output (Max)：-
Current - Output：1.5A
Frequency - Switching：400kHz ~ 800kHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount
Package / Case：30-VFQFN Exposed Pad
Supplier Device Package：30-QFN (5x5)
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for XR76201EL

XR76201EL

Voltage Regulators - DC DC Switching Regulators Overview

The XR76201EL is a positive adjustable buck switching regulator IC from MaxLinear, operating within the PowerBlox series. It integrates a step-down converter topology with an output current capability of 1.5A. The device utilizes a 30-pin QFN package and supports CV025MJ00001/0.25 um CMOS technology. As an obsolete product, it functions as a DC-DC switching regulator designed for voltage regulation applications.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Integrates step-down converter functionality in a compact form factor
Supports positive adjustable output voltage configuration
Utilizes PowerBlox series architecture for point-of-load supplies

Voltage Regulators - DC DC Switching Regulators Applications

Point-of-load voltage regulation
DC-DC switching regulator circuits
Voltage regulation systems requiring integrated buck conversion

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify component status carefully as this part is listed as obsolete. Confirm availability through secondary markets or authorized distributors handling legacy inventory. Ensure compatibility with existing designs before sourcing, as replacement components may require schematic adjustments. Check RoHS compliance details via official documentation.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Consider the 1.5A output limit when designing load requirements. The 30QFN package dictates specific PCB layout constraints. Evaluate thermal management needs given the integrated nature of the regulator. Compare against newer MaxLinear alternatives if long-term supply stability is required for production volumes.

Voltage Regulators - DC DC Switching Regulators Part Context

Part of the MaxLinear PowerBlox series, which combines controller, drivers, bootstrap diode, and MOSFETs in a single package. This integration simplifies design for synchronous buck regulators. The XR76201EL specifically targets applications needing moderate current levels in a small footprint.
