XSCBD23MB

LED Indication - Discrete Overview

The XSCBD23MB is a discrete blue LED indicator manufactured by SunLED, emitting light at a wavelength of 465nm. It features a square lens with a flat top design and a diffused clarity level, housed in a radial through-hole package. The component has a lens size of 5.00mm and provides a viewing angle of 110 degrees. Typical forward voltage is 3.3V, measured at a test current of 20mA. The optical lens tint is white, and the LED brightness is specified at 29mcd.

LED Indication - Discrete Feature Summary

• Blue light emission with diffused lens for broad visibility
• Square flat-top lens design with radial through-hole mounting
• High viewing angle for wide-area indication

LED Indication - Discrete Applications

• Discrete status indication in electronic devices
• Panel mount indicators requiring radial leaded components
• Visual signaling in consumer electronics assemblies

LED Indication - Discrete Procurement Notes

Verify the specific part number XSCBD23MB against official SunLED datasheets to confirm electrical parameters such as forward voltage and test current. Ensure the radial through-hole package type matches the target PCB layout requirements. Cross-reference the blue wavelength and diffused lens specifications to guarantee compatibility with optical visibility needs. Confirm RoHS compliance status if required by project regulations.

LED Indication - Discrete Selection Notes

Select this component when a blue discrete LED with radial leads is required for panel or board mounting. The diffused lens and 110-degree viewing angle make it suitable for applications needing wide-angle visibility. Consider the 3.3V typical forward voltage for circuit design compatibility. The square flat-top lens style offers a distinct aesthetic compared to round lenses.

LED Indication - Discrete Part Context

SunLED is an ISO9001 and ISO14001 certified manufacturer established in 1989, specializing in optoelectronic components including LEDs and displays. The company produces millions of LEDs monthly, serving both startup and large-scale OEM customers globally. This component represents their discrete LED offering for standard indication applications.

LED Indication - Discrete Replacement Considerations

Consult official SunLED documentation for direct substitutes. Verify that any alternative maintains the same radial package, blue wavelength, and similar forward voltage characteristics to ensure functional equivalence in existing designs.
