XSCEGCNANF-10.000000

Crystals Overview

The XSCEGCNANF-10.000000 is a surface-mount fundamental quartz crystal manufactured by Taitien, designed for precision frequency control applications. It operates at a nominal frequency of 10.0000 MHz with a load capacitance of 10 pF and an equivalent series resistance of 150 Ohms. The component features a frequency tolerance of ±30 ppm and utilizes a 2-SMD, No Lead package configuration. This parallel resonant device supports standard through-hole or surface-mount integration depending on the specific circuit design requirements.

Crystals Feature Summary

• Surface-mount fundamental quartz crystal construction
• Precision frequency stability for timing circuits
• Low power consumption suitable for portable electronics

Crystals Applications

• Microcontroller clock sources
• Digital communication interfaces
• Portable electronic devices

Crystals Procurement Notes

Verify RoHS compliance status and current production lifecycle stage before procurement. Confirm exact package dimensions against target PCB footprint. Ensure supplier provides valid manufacturer traceability documentation to guarantee component authenticity and performance consistency.

Crystals Selection Notes

Select this component when a 10 MHz surface-mount crystal with 10 pF load capacitance is required. Consider the ±30 ppm tolerance limit for application timing accuracy needs. Evaluate the 150 Ohm ESR against oscillator circuit drive level specifications to ensure stable operation.

Crystals Part Context

This part belongs to Taitien’s SMD crystal lineup, utilizing standard surface-mount packaging for automated assembly. It serves as a passive frequency control element within larger electronic systems, providing the necessary reference clock signal for digital logic and communication protocols.

Crystals Replacement Considerations

Cross-reference with other 10 MHz SMD crystals from Taitien having identical 10 pF load capacitance and similar ESR values. Verify mechanical footprint compatibility and electrical parameter alignment before substitution.

Crystals FAQ

What is the load capacitance value?

The load capacitance is 10 pF.

What is the frequency tolerance?

The frequency tolerance is ±30 ppm.
