XTL571300-B29-521

Crystals Overview

The Siward XTL571300-B29-521 is a surface-mount MHz crystal resonator belonging to the XTL57 series. It operates at a nominal frequency of 24 MHz with a load capacitance of 10 pF and a frequency tolerance of ±30 ppm. The component utilizes a ceramic SMD package with dimensions of 3.2 x 2.5 mm and features a four-terminal no-lead configuration. It exhibits an equivalent series resistance (ESR) of 80 Ohms and employs vacuum seam sealing technology for environmental protection.

Crystals Feature Summary

• Utilizes a ceramic SMD package structure
• Employs vacuum seam sealed construction
• Features ultra-thin profile design

Crystals Applications

• Mobile communication devices
• Bluetooth modules
• Wireless LAN systems

Crystals Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm electrical parameters, including the 24 MHz frequency, 10 pF load capacitance, and ±30 ppm tolerance. Ensure the ceramic package type matches system requirements. Cross-reference datasheets from authorized distributors to validate authenticity and technical specifications before procurement.

Crystals Selection Notes

Select this component for applications requiring a compact 3.2 x 2.5 mm footprint and stable 24 MHz timing. Consider the 80 Ohm ESR and 10 pF load capacitance when designing oscillator circuits. The vacuum-sealed ceramic package offers reliability suitable for consumer electronics and wireless communication hardware where space constraints are critical.

Crystals Part Context

This component is part of the Siward XTL57 series of quartz crystals. The series includes various frequencies and packages, such as the XTL571300-U11-279 and XTL571300LLI24.000-10TR. These parts are designed for high-reliability frequency control in portable and wireless electronic devices, leveraging Siward's expertise in quartz frequency control elements established since 1988.

Crystals Replacement Considerations

Compatible substitutes include other 24 MHz ceramic SMD crystals with identical 3.2 x 2.5 mm dimensions and 10 pF load capacitance. Verify that alternative components meet the ±30 ppm tolerance and 80 Ohm ESR specifications to ensure circuit compatibility without redesign.
