XTL581100-A263-021

Crystals Overview

The XTL581100-A263-021 is a surface-mount crystal manufactured by Siward. It operates at a fundamental frequency of 40 MHz with a load capacitance of 10 pF. The component features a compact 2.5 x 2.0 mm package footprint, suitable for space-constrained designs. This specific part number represents a standard crystal resonator designed for precision timing applications in electronic circuits.

Crystals Feature Summary

• Provides stable oscillation at 40 MHz
• Compact 2.5 x 2.0 mm surface mount form factor
• Designed for 10 pF load capacitance environments

Crystals Applications

• Communications equipment
• Broadband fixed line access systems

Crystals Procurement Notes

Verify the manufacturer part number against official Siward documentation to ensure authenticity. Confirm that the required load capacitance and frequency tolerance align with your circuit design specifications before procurement. Check for any specific handling requirements related to surface-mount crystal components.

Crystals Selection Notes

Select this component when a 40 MHz reference signal is required within a 2.5 x 2.0 mm footprint constraint. Ensure the target application supports a 10 pF load capacitance configuration. Consider the mechanical stability and thermal characteristics appropriate for the intended operating environment.

Crystals Part Context

This part belongs to Siward's portfolio of surface-mount crystals. It is categorized under passive components used for frequency control. The product line typically includes various frequencies and package sizes tailored for consumer electronics and industrial communication devices requiring precise clock signals.

Crystals Replacement Considerations

Consult official Siward substitution guides for compatible alternatives. Verify that any substitute matches the 40 MHz frequency, 10 pF load capacitance, and 2.5 x 2.0 mm dimensions exactly to maintain circuit performance.
