XTL581150-M118-181

Crystals Overview

The Siward XTL581150-M118-181 is a surface-mount quartz crystal resonator designed for precision frequency control applications. It operates at a fundamental frequency of 26 MHz and features a load capacitance of 8 pF. The component utilizes a 4-SMD, no-lead package with physical dimensions of 2.5 mm in length and 2.0 mm in width. This configuration supports compact circuit designs while maintaining stable oscillation characteristics suitable for various electronic systems requiring reliable timing signals.

Crystals Feature Summary

• Compact surface-mount design for space-constrained PCB layouts
• Stable oscillation performance at 26 MHz
• Integrated 8 pF load capacitance specification

Crystals Applications

• Wireless communication modules
• Mobile device clock circuits
• IoT sensor interfaces

Crystals Procurement Notes

Verify the specific ordering suffix M118-181 against the manufacturer's current datasheet to ensure compatibility with required tolerance and temperature range specifications. Confirm that the 4-SMD package matches the target footprint and soldering profile requirements before finalizing procurement orders.

Crystals Selection Notes

Select this component when a 26 MHz reference signal is required within a 2.5 x 2.0 mm envelope. Ensure the circuit design accounts for the specified 8 pF load capacitance to achieve accurate frequency stability. Evaluate thermal requirements against the standard operating range for the intended application environment.

Crystals Part Context

This part belongs to Siward's SXT-2520 series of miniature quartz crystals. The series emphasizes miniaturization and high stability for modern electronics. The XTL581150 designation indicates the specific product line within the company's portfolio of frequency control components.

Crystals Replacement Considerations

Consult official substitution lists for equivalent 26 MHz crystals in 4-SMD packages. Verify dimensional compatibility and electrical parameters such as load capacitance and frequency tolerance before replacing the original component.
