XTL5C1-Q23-064

Crystals Overview

The Siward XTL5C1-Q23-064 is a thermistor crystal operating at a nominal frequency of 76.8 MHz. It features a load capacitance of 7pF and an ESR of 30 Ohms. The frequency tolerance is specified as -10ppm to +22ppm. The component utilizes a 4-SMD, No Lead package with dimensions of 0.065 inches in length.

Crystals Feature Summary

• Incorporates integrated thermistor technology for enhanced thermal stability
• Designed for high reliability under demanding automotive conditions
• Utilizes a compact surface-mount package suitable for automated assembly

Crystals Applications

• Automotive electronic systems requiring precise timing
• High-stability clock generation circuits
• Thermal-compensated oscillator designs

Crystals Procurement Notes

Verify the specific ordering suffix and package variant against the official Siward datasheet to ensure compatibility with your design requirements. Confirm that the thermistor functionality aligns with your thermal management strategy. Check for any recent updates to the RoHS compliance status or manufacturing location before finalizing procurement orders.

Crystals Selection Notes

Select this component when automotive-grade stability and integrated thermal compensation are required. Ensure the 76.8 MHz frequency matches your system clock needs. Verify that the 4-SMD no-lead footprint fits your PCB layout constraints. Consider the -10ppm/+22ppm tolerance range for your application's precision requirements.

Crystals Part Context

This part belongs to Siward's automotive-grade thermistor crystal series. These components combine quartz resonance with built-in temperature sensing. The XTL5C1-Q23-064 specifically targets applications needing robust performance in varying thermal environments without external compensation circuits.

Crystals Replacement Considerations

Consult official substitution lists for direct equivalents. Cross-reference pinout and electrical parameters carefully. Verify package dimensions match existing footprints. Ensure frequency and tolerance specifications remain compatible with the target circuit design.
