XTL92-U11-580

Crystals Overview

The Siward XTL92-U11-580 is a miniature quartz crystal resonator designed for surface-mount applications. It operates at a fundamental frequency of 59.97 MHz with a load capacitance of 8 pF and an equivalent series resistance of 50 Ohms. The component exhibits a frequency tolerance of ±9 ppm. It utilizes a lead-free 4-SMD package with physical dimensions of 1.0 mm by 0.8 mm and a height of 0.3 mm, ensuring compatibility with automated assembly processes.

Crystals Feature Summary

• Ultra-miniature 1008 footprint design suitable for space-constrained electronics
• Lead-free construction compliant with environmental standards
• High stability performance for precise timing requirements

Crystals Applications

• Wearable electronic devices
• Internet of Things (IoT) modules
• System-in-Package (SiP) implementations
• Compact wireless communication equipment

Crystals Procurement Notes

Verify the specific ordering suffix to confirm exact frequency tolerance and load capacitance specifications before procurement. Ensure that the selected variant matches the target circuit's load requirements. Confirm lead-free status and RoHS compliance through official manufacturer documentation or authorized distributor datasheets to guarantee regulatory adherence.

Crystals Selection Notes

Select this component when board real estate is limited due to its 1.0 x 0.8 mm package size. Consider the ±9 ppm tolerance for clock generation needs where moderate precision is sufficient. Evaluate the 8 pF load capacitance against the microcontroller or oscillator input requirements to ensure proper oscillation startup and frequency accuracy without external trimming.

Crystals Part Context

This part belongs to the XTL92 series from Siward, which focuses on ultra-miniature MHz crystals. The series targets modern portable electronics requiring high density. Unlike larger industrial crystals, these units prioritize minimal profile and small footprint while maintaining reliable operation in consumer-grade environments.

Crystals Replacement Considerations

Direct substitutes must match the 59.97 MHz frequency, 8 pF load capacitance, and 1.0 x 0.8 mm SMD package. Verify equivalent ESR and tolerance ratings. Cross-reference with other manufacturers offering 1008 format crystals to ensure pinout compatibility and thermal characteristics align with the original design.

Crystals FAQ

What is the physical height of the XTL92-U11-580?

The maximum height of the component is 0.3 mm.

Is this crystal lead-free?

Yes, the XTL92-U11-580 is specified as a no-lead device.
