XZCBD55W-1

$0.31

Description：LED BLUE CLEAR CHIP SMD
Series：-
Mfr：SunLED
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:84d061f220e8 Category: LED Indication - Discrete Brand: SunLED

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

XZCBD55W-1 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists SunLED. Its product description is LED BLUE CLEAR CHIP SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for XZCBD55W-1

Description：LED BLUE CLEAR CHIP SMD
Series：-
Mfr：SunLED
Package：Tape & Reel (TR),Cut Tape (CT)
Color：Blue
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：98mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.90mm x 1.60mm
Voltage - Forward (Vf) (Typ)：3.3V
Current - Test：20mA
Viewing Angle：120°
Mounting Type：Surface Mount
Wavelength - Dominant：465nm
Wavelength - Peak：460nm
Features：-
Package / Case：1206 (3216 Metric)
Supplier Device Package：Chip LED
Size / Dimension：3.20mm L x 1.60mm W
Height (Max)：0.75mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for XZCBD55W-1

XZCBD55W-1

LED Indication - Discrete Overview

The SunLED XZCBD55W-1 is a blue surface-mount LED indicator designed for high visibility in compact spaces. It utilizes InGaN technology to emit light at a wavelength of 460nm with a typical forward voltage of 3.3V. The component features a water-clear lens and offers a wide viewing angle of 120 degrees, ensuring effective signal indication across various orientations.

LED Indication - Discrete Feature Summary

InGaN blue emission technology
Water-clear lens design
Wide 120-degree viewing angle

LED Indication - Discrete Applications

Status indication on electronic boards
Compact device signaling
Surface-mount assembly integration

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix against official SunLED documentation to confirm exact optical and electrical characteristics. Ensure compatibility with standard SMT reflow processes and check RoHS compliance status prior to procurement.

LED Indication - Discrete Selection Notes

Select this component for applications requiring a standard blue indicator with a clear lens. Consider the 1206 package size for space-constrained designs. Verify thermal management requirements for continuous operation at specified test currents.

LED Indication - Discrete Part Context

This part belongs to SunLED's discrete LED indicator series, focusing on surface-mount solutions. The manufacturer specializes in optoelectronic components compliant with environmental standards, providing reliable lighting solutions for industrial and consumer electronics markets.
