XZDGK78WHTA-RT

LED Indication - Discrete Overview

The XZDGK78WHTA-RT is a single-color green surface-mount LED component manufactured by SunLED. It features a clear lens with a rectangular, flat-top style and operates at a dominant wavelength of 525nm. The device is housed in a compact 3.2mm x 2.4mm SMD package with a maximum height of 1.00mm. It supports a forward current of 20mA and provides a viewing angle of 20 degrees. The unit is RoHS compliant and suitable for standard surface-mount assembly processes.

LED Indication - Discrete Feature Summary

• Green light emission with a 525nm dominant wavelength
• Compact 3.2mm x 2.4mm surface-mount package design
• Clear rectangular flat-top lens configuration
• Standard 20mA forward current operation

LED Indication - Discrete Applications

• Electronic equipment status indicators
• Control panel illumination
• Consumer appliance signaling
• General-purpose visual indication

LED Indication - Discrete Procurement Notes

Verify the specific suffix 'HTA-RT' against official SunLED documentation to confirm handling and tape specifications. Ensure compatibility with standard reflow soldering profiles for 2-SMD components. Confirm that the 20mA forward current rating aligns with the target circuit design requirements before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component when a low-profile green indicator is required for space-constrained printed circuit board layouts. The 20-degree viewing angle directs light primarily perpendicular to the surface, making it ideal for applications where side-viewing visibility is not critical. Ensure the 3.2mm x 2.4mm footprint matches the available PCB copper pads.

LED Indication - Discrete Part Context

This part belongs to the SunLED SMD LED series, which focuses on providing reliable optoelectronic solutions for modern electronics manufacturing. As an ISO9001 and ISO14001 certified manufacturer, SunLED ensures consistent quality across its product lines. The XZDGK78WHTA-RT represents a standard offering within their green LED portfolio, designed for high-volume production environments.

LED Indication - Discrete Replacement Considerations

The XZDGK78W is listed as a related part number. Verify if the base model without the specific suffix meets the mechanical and electrical requirements. Cross-reference datasheets to ensure identical package dimensions and optical characteristics before substitution.
