YC4032M00033T1521023

Oscillators Overview

The YC4032M00033T1521023 is a standard crystal oscillator (XO) manufactured by Hefei Jingweite Electronics Co., Ltd. It operates at a frequency of 32 MHz with CMOS output logic. The device requires a supply voltage of 3.3V and supports enable/disable functionality. It features a maximum supply current of 10mA and functions within an operating temperature range of -40°C to 85°C. The component utilizes a surface-mount 4-SMD, no-lead package design.

Oscillators Feature Summary

• CMOS output interface for digital signal compatibility
• Enable/Disable control function for power management
• Surface-mount construction for automated assembly

Oscillators Applications

• General electronic circuit timing references
• Embedded system clock generation
• Consumer electronics timing applications

Oscillators Procurement Notes

Verify the manufacturer part number YC4032M00033T1521023 against official Hefei Jingweite Electronics documentation to confirm specifications. Ensure the required 3.3V supply voltage and CMOS load conditions match the target circuit design. Confirm the -40°C to 85°C industrial temperature rating meets environmental requirements before procurement.

Oscillators Selection Notes

Select this component when a 32 MHz CMOS clock source is required in a compact surface-mount form factor. Consider the enable/disable feature if dynamic power control is necessary. Verify that the 4-SMD package dimensions fit the available PCB space and that the 10mA current draw aligns with the power budget constraints of the application.

Oscillators Part Context

This oscillator belongs to the standard XO category from Hefei Jingweite Electronics, a manufacturer specializing in quartz frequency devices. The company integrates R&D, production, and sales of crystal components. This specific model represents a common frequency solution for general-purpose timing needs in modern electronic assemblies.

Oscillators Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Cross-referencing requires matching frequency, output type, voltage, and package dimensions with other manufacturers' catalogs.
