YMC08DAAN is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Sullins Connector Solutions. Its product description is CONN HEADER VERT 16POS 2.54MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for YMC08DAAN
- Description：CONN HEADER VERT 16POS 2.54MM
- Series：-
- Mfr：Sullins Connector Solutions
- Package：Bulk
- Connector Type：Header, Breakaway
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：16
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.230" (5.84mm)
- Contact Length - Post：0.120" (3.05mm)
- Overall Contact Length：0.450" (11.43mm)
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：30.0µin (0.76µm)
- Contact Finish - Post：Gold
- Contact Material：Beryllium Copper
- Insulation Material：Polyetheretherketone (PEEK)
- Features：-
- Operating Temperature：-65°C ~ 250°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Tan
- Current Rating (Amps)：3A
- Voltage Rating：-
Headers, Male Pins datasheet and documents for YMC08DAAN
Headers, Male Pins Overview
The YMC08DAAN is a high-temperature card edge connector manufactured by Sullins Connector Solutions. It features a dual row configuration with 12 positions and a 0.100-inch (2.54mm) pitch. The connector utilizes male pin contacts with gold plating for reliable signal transmission. Designed for through-hole mounting, it supports board-to-board or cable applications. The unit operates within an extended temperature range suitable for demanding environments.
Headers, Male Pins Feature Summary
- High-temperature rated construction for thermal stability
- Dual row male header design for vertical mounting
- Gold-plated cylindrical contact surfaces for durability
Headers, Male Pins Applications
- Board-to-board interconnects
- Cable assembly connections
- High-temperature electronic modules
Headers, Male Pins Procurement Notes
Verify the specific suffix against official manufacturer documentation to confirm exact contact length and insulation material properties. Ensure compatibility with mating female connectors regarding pitch and row spacing. Confirm RoHS3 compliance status for regulatory requirements before finalizing procurement orders.
Headers, Male Pins Selection Notes
Select this component when high-temperature performance is required alongside a dual-row male header configuration. The 0.100-inch pitch suits standard density layouts. Verify that the through-hole mounting style aligns with the target PCB fabrication capabilities and mechanical stress requirements.
Headers, Male Pins Part Context
This part belongs to the Sullins Connector Solutions catalog of industrial and commercial interconnect solutions. The series focuses on robust card edge and header technologies designed for mission-critical applications across various sectors requiring reliable electrical connectivity under challenging conditions.
Headers, Male Pins FAQ
What is the contact type for this connector?
The YMC08DAAN features male pin contacts with a cylindrical shape.
Is this connector suitable for high-temperature environments?
Yes, the product description explicitly identifies it as a high-temperature connector.
