YN4024M00033T1521030

Oscillators Overview

The YN4024M00033T1521030 is a crystal oscillator (XO) manufactured by Hefei Jingweite Electronics Co., Ltd. It operates at a nominal frequency of 24.0000 MHz with CMOS output logic. The component utilizes a surface-mount device (SMD) package, specifically a 4-SMD, no-lead case configuration. Physical dimensions are 0.081 inches in length and 0.065 inches in width, equivalent to 2.05 mm x 1.65 mm. The device supports an operating temperature range from -40°C to +85°C.

Oscillators Feature Summary

• Generates a stable 24 MHz clock signal using CMOS output interface
• Designed for compact surface-mount assembly on printed circuit boards
• Operates reliably within industrial temperature environments

Oscillators Applications

• Digital signal processing systems requiring precise timing references
• Microcontroller-based embedded devices
• Communication equipment clock synchronization

Oscillators Procurement Notes

Verify the manufacturer part number YN4024M00033T1521030 against official Hefei Jingweite Electronics documentation to confirm specifications. Ensure compatibility with the target voltage supply and load requirements. Check for any specific handling instructions related to the 4-SMD no-lead package during assembly processes.

Oscillators Selection Notes

Select this component when a 24 MHz CMOS clock source is required in a small 2.05mm x 1.65mm footprint. Consider the -40°C to +85°C operating range for suitability in industrial or automotive applications. Confirm that the CMOS output drive strength meets the input requirements of the connected digital logic circuits.

Oscillators Part Context

This oscillator belongs to the XTAL OSC XO series from Hefei Jingweite Electronics. It is categorized under crystal oscillators and resonators. The product serves as a timebase generator for electronic circuits, providing a stable frequency reference compared to discrete crystal components which require external oscillator circuits.

Oscillators Replacement Considerations

No public substitute part numbers are confirmed in the available data. Verify pinout and electrical parameters before considering alternative manufacturers.
