Z0201C220APMST

Description：FERRITE BEAD 22 OHM 0201 1LN
Series：Z-PMS
Mfr：KEMET
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:b22ee3c1e45a Category: Ferrite Beads and Chips Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FERRITE BEAD 22 OHM 0201 1LN
Series：Z-PMS
Mfr：KEMET
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：1
Impedance @ Frequency：22 Ohms @ 100 MHz
Current Rating (Max)：-
DC Resistance (DCR) (Max)：-
Ratings：-
Operating Temperature：-55°C ~ 125°C
Package / Case：0201 (0603 Metric)
Mounting Type：Surface Mount
Height (Max)：0.013" (0.33mm)
Size / Dimension：0.024" L x 0.012" W (0.60mm x 0.30mm)
Features：-

Download product information

Z0201C220APMST

Overview

The KEMET Z0201C220APMST is a surface-mount ferrite bead designed for high-frequency noise suppression in compact electronic circuits. It features a 0201 (0603 metric) package, providing a small footprint suitable for dense PCB layouts. The component exhibits an impedance of 22 Ohms at a frequency of 100 MHz and supports a current rating of 1 Ampere. It operates reliably within a temperature range of -55°C to +125°C, ensuring stability under varying thermal conditions.

Feature Summary

Provides effective electromagnetic interference filtering through high impedance characteristics at target frequencies
Utilizes a miniature 0201 surface-mount package to maximize board space efficiency
Maintains stable performance across a wide industrial operating temperature range

Applications

High-speed digital signal line noise suppression
Power supply input/output filtering
Compact consumer electronics circuit protection

Procurement Notes

Verify the specific impedance tolerance and DC resistance values against the official manufacturer datasheet prior to integration. Confirm that the selected package size aligns with the automated assembly capabilities of the manufacturing facility. Ensure that the maximum current rating meets the operational requirements of the target circuit to prevent thermal degradation.

Selection Notes

Select this component when space constraints require a 0201 footprint for noise control applications. Evaluate the impedance curve at the specific noise frequency to ensure adequate attenuation. Consider the current handling capability relative to the circuit load to maintain reliability. Compare alternative packages if higher current capacity or different impedance profiles are required for the design.

Part Context

This ferrite bead belongs to KEMET's portfolio of passive components focused on signal integrity and power management. Ferrite beads function as frequency-dependent resistors, dissipating high-frequency energy as heat. They are essential for mitigating electromagnetic interference in modern electronics where component density and switching speeds are increasing.
