Z1810C102BPWZT

Overview

The KEMET Z1810C102BPWZT is a surface-mount ferrite chip bead designed for noise suppression in electronic circuits. It features a 1810 package dimension and provides an impedance of 494.9 ohms at its rated frequency. The component supports a maximum DC current of 2 amperes with a typical DC resistance of 60 milliohms. It operates within a temperature range of -55°C to +125°C and complies with RoHS standards.

Feature Summary

• Provides high impedance noise attenuation for signal integrity
• Supports high continuous DC current loads
• Utilizes standard surface-mount termination for automated assembly

Applications

• High-speed data line filtering
• Power supply output noise suppression
• EMI reduction in compact electronic modules

Procurement Notes

Verify the specific impedance value and DC resistance against the official datasheet, as values may vary by frequency and manufacturer lot. Confirm the package dimensions match the design footprint. Ensure the operating temperature range meets the environmental requirements of the final application. Check for any end-of-life notices or obsolescence warnings from the manufacturer before finalizing procurement plans.

Selection Notes

Select this component when high impedance at specific frequencies is required alongside high current handling capabilities. The 1810 package offers a balance between size and power dissipation. Consider the DC resistance impact on voltage drop in low-voltage applications. Verify compatibility with reflow soldering profiles specified in the datasheet to ensure reliable joint formation during manufacturing.

Part Context

This part belongs to the KEMET Z-PWZ series of ferrite beads, which are engineered for effective electromagnetic interference suppression. The series utilizes advanced ferrite materials to provide stable performance across wide temperature ranges. These components are commonly used in consumer electronics, industrial controls, and automotive systems where space constraints and noise immunity are critical design factors.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's cross-reference tools or authorized distributors for verified alternatives that meet identical electrical and mechanical specifications.
