ZBSS-10G-S+

Overview

The ZBSS-10G-S+ is a suspended substrate band pass filter manufactured by Mini-Circuits. It operates within a frequency range of 8000 to 12000 MHz, with a center frequency of 10000 MHz. The component features SMA connectors and maintains a system impedance of 50 Ohms. Typical insertion loss ranges from 1 to 2.5 dB at 25°C.

Feature Summary

• Combines low insertion loss with wide stopband performance
• Utilizes suspended substrate technology for signal conditioning
• Designed for high-reliability RF applications

Applications

• Wideband instruments
• Electronic countermeasure (ECM) systems
• RF and microwave test equipment

Procurement Notes

Verify the specific datasheet revision when sourcing this component. Confirm that the SMA connector type matches your system interface requirements. Ensure the operating environment remains within the specified temperature limits to maintain the typical insertion loss characteristics documented in the official Mini-Circuits specifications.

Selection Notes

Select this model when a precise 10 GHz center frequency is required with a 4 GHz bandwidth. The suspended substrate construction offers a balance between performance and size. Consider the 50 Ohm impedance match for standard RF systems. Evaluate the insertion loss specifications against system noise budget requirements before finalizing the design integration.

Part Context

This component belongs to the ZBSS series from Mini-Circuits, which specializes in suspended substrate band pass filters. The series is engineered to provide reliable signal filtering for demanding radio frequency environments. Mini-Circuits designs these components to meet strict quality standards for aerospace, defense, and telecommunications sectors.

Replacement Considerations

Consult the official Mini-Circuits database for direct substitutes. Verify that any alternative part maintains the same 8000 to 12000 MHz frequency range and SMA interface compatibility.
