ZJYS5105-2PLT-01

Description：CMC 5A 2LN 100 OHM SMD
Series：ZJYS51
Mfr：TDK Corporation
Package：Tape & Reel (TR)

SKU:fb591999eadd Category: Common Mode Chokes Brand: TDK Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 5A 2LN 100 OHM SMD
Series：ZJYS51
Mfr：TDK Corporation
Package：Tape & Reel (TR)
Filter Type：Signal Line
Number of Lines：2
Current Rating (Max)：5A
DC Resistance (DCR) (Max)：10mOhm
Voltage Rating - DC：50V
Voltage Rating - AC：-
Operating Temperature：-25°C ~ 85°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.413" L x 0.354" W (10.50mm x 9.00mm)
Height (Max)：0.200" (5.08mm)
Package / Case：Horizontal, 4 Gull Wing
Inductance @ Frequency：-
Impedance @ Frequency：100 Ohms @ 100 MHz
Qualification：-
Grade：-

Download product information

ZJYS5105-2PLT-01

Overview

The ZJYS5105-2PLT-01 is a surface mount common mode choke manufactured by TDK Corporation. It features a DC voltage rating of 50V and an impedance of 100 Ohms. The component supports a current rating of 5A and operates within a temperature range of -25°C to 85°C.

Feature Summary

Provides common mode noise suppression for two-line circuits
Designed for surface mount technology integration
Rated for 50V DC operation

Applications

Power supply filtering
Battery charger circuits
Portable device protection

Procurement Notes

Verify the specific manufacturer datasheet for detailed electrical characteristics, mechanical dimensions, and soldering guidelines. Confirm that the component meets all necessary regulatory compliance standards required for your specific end-use application before finalizing procurement decisions.

Selection Notes

Select this component when a 5A current handling capability and 100 Ohm impedance are required for common mode noise reduction in low-voltage DC applications. Ensure the operating environment stays within the specified -25°C to 85°C temperature range for reliable performance.

Part Context

This part belongs to TDK's line of surface mount common mode chokes. These components are engineered to suppress electromagnetic interference in compact electronic designs, offering a balance between high current capacity and effective noise attenuation for sensitive circuitry.

Replacement Considerations

Consult official TDK documentation or authorized distributors to identify verified substitute part numbers with matching electrical specifications and form factors.
