ZJYS81R5-2P50T-G01

Overview

The ZJYS81R5-2P50T-G01 is a surface-mount data line filter manufactured by TDK Corporation. It features two functions with a rated voltage of 80 V and a maximum current of 0.5 A. The component exhibits an impedance of 2000 ohms at 10 MHz and a maximum DC resistance of 0.25 ohms. It operates within a temperature range of -40 °C to 125 °C and complies with RoHS standards.

Feature Summary

• Provides common mode noise suppression for signal lines
• Designed for compact surface-mount integration
• Compliant with automotive reliability standards

Applications

• Automotive data bus protection
• High-speed signal line filtering
• Electronic equipment EMI mitigation

Procurement Notes

Verify the specific suffix G01 against official TDK documentation to confirm package and compliance details. Ensure the selected variant matches the required impedance and current ratings for the target circuit design before procurement.

Selection Notes

Select this component for applications requiring robust noise filtering in space-constrained environments. Consider the 0.5 A current rating and 80 V voltage limit when designing the circuit to ensure reliable operation under expected load conditions.

Part Context

This part belongs to the ZJYS81 series of surface-mount filters from TDK. These components are engineered for high-performance noise suppression in digital communication interfaces, offering a balance between low insertion loss and effective interference rejection.

Replacement Considerations

Public confirmed substitute part numbers: ZJYS81R5-2P50T-G01.
