Product Detailed Parameters
- Description：RF FILTER LOW PASS 14GHZ MODULE
- Series：ZLSS
- Mfr：Mini-Circuits
- Package：Bulk
- Frequency：14GHz
- Bandwidth：-
- Filter Type：Low Pass
- Ripple：-
- Insertion Loss：3dB
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Size / Dimension：0.900" L x 0.700" W (22.86mm x 17.78mm)
- Height (Max)：0.650" (16.51mm)
Download product information
Overview
The ZLSS-14G-S+ is a suspended substrate low-pass filter manufactured by Mini-Circuits, designed for radio frequency applications. It operates from DC to 14 GHz with a nominal impedance of 50 Ohms. The component utilizes SMA connectors for termination and is housed in the RA2456 case style. It complies with RoHS and REACH standards, ensuring environmental safety for electronic assemblies.
Feature Summary
- Suspended substrate technology for high-frequency performance
- Wideband operation up to 14 GHz cutoff
- Standard 50 Ohm impedance matching
Applications
- RF signal conditioning
- Harmonic suppression in RF circuits
- Test and measurement equipment
Procurement Notes
Verify the specific datasheet revision (e.g., REV.A) against your design requirements. Confirm that the SMA connector type matches your system interface. Ensure the RA2456 package dimensions fit your PCB layout constraints before finalizing procurement.
Selection Notes
Select this component when a wide bandwidth up to 14 GHz is required. The 50 Ohm impedance suits standard RF systems. Consider the suspended substrate construction for superior high-frequency characteristics compared to planar alternatives.
Part Context
This part belongs to the ZLSS series of suspended substrate low-pass filters from Mini-Circuits. These components are engineered for demanding RF environments, offering robust performance across a broad frequency spectrum while maintaining compact physical dimensions suitable for modern electronics.
Replacement Considerations
Check for direct substitutes within the ZLSS series or other Mini-Circuits low-pass filters with similar cutoff frequencies. Verify compatibility regarding connector types and impedance levels before substitution.
FAQ
What is the cutoff frequency of the ZLSS-14G-S+?
The cutoff frequency is 14 GHz.
What type of connectors does this filter use?
It uses SMA connectors for input and output termination.
