ZLSS-3R2G-S+

$257.99

Description：RF FILTER LOW PASS 3.2GHZ MODULE
Series：-
Mfr：Mini-Circuits
Package：Bulk

SKU:2166cd15349a Category: RF Filters Brand: Mini-Circuits

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER LOW PASS 3.2GHZ MODULE
Series：-
Mfr：Mini-Circuits
Package：Bulk
Frequency：3.2GHz (Cutoff)
Bandwidth：-
Filter Type：Low Pass
Ripple：-
Insertion Loss：2dB
Mounting Type：Chassis Mount
Package / Case：Module, SMA Connectors
Size / Dimension：0.900" L x 0.700" W (22.86mm x 17.78mm)
Height (Max)：0.650" (16.51mm)

Download product information

ZLSS-3R2G-S+

Overview

The ZLSS-3R2G-S+ is a suspended substrate low pass filter manufactured by Mini-Circuits. It provides signal conditioning with a frequency range from DC to 3.2 GHz. The component features a 50-ohm impedance and utilizes SMA connectors for interface. Key electrical specifications include a cutoff frequency of 3.2 GHz, a stopband extending up to 20 GHz, and an insertion loss ranging from 0.6 to 2 dB.

Feature Summary

Suspended substrate construction for enhanced RF performance
Low pass filtering capability up to 20 GHz stopband
Integrated SMA connectors for direct circuit integration

Applications

RF signal conditioning in communication systems
Harmonic suppression in transmitter chains
Interference mitigation in receiver front ends

Procurement Notes

Verify the specific datasheet version provided by Mini-Circuits or authorized distributors to confirm current manufacturing status and exact electrical tolerances. Ensure compatibility with existing SMA connector interfaces and PCB layout requirements before finalizing procurement decisions.

Selection Notes

Select this component when a low pass filter with a 3.2 GHz cutoff is required for 50-ohm systems. The suspended substrate design offers distinct advantages over standard microstrip filters regarding power handling and linearity. Confirm that the 0.6 to 2 dB insertion loss meets system link budget constraints.

Part Context

This part belongs to the ZLSS series of suspended substrate low pass filters from Mini-Circuits. The series is characterized by robust construction and consistent performance across various RF applications. The ZLSS-3R2G-S+ specifically targets frequencies up to 3.2 GHz, fitting within the broader portfolio of signal conditioning components designed for high-frequency reliability.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific model. Evaluate other ZLSS series variants only if frequency specifications align with application requirements.
