ZR40402F41TA

$0.27

Description：IC VREF SHUNT 4.096V SOT23
Series：-
Mfr：Diodes Incorporated
Package：Tape & Reel (TR)

SKU:50e4f923aa51 Category: Voltage Reference Brand: Diodes Incorporated

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC VREF SHUNT 4.096V SOT23
Series：-
Mfr：Diodes Incorporated
Package：Tape & Reel (TR)
Output Type：-
Voltage - Output (Min/Fixed)：-
Voltage - Output (Max)：-
Current - Output：-
Operating Temperature：-
Mounting Type：-
Package / Case：-
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

ZR40402F41TA

Overview

The ZR40402F41TA is a shunt voltage reference manufactured by Diodes Incorporated, designed for surface-mount applications in the SOT-23-3 package. It provides a fixed output voltage of 4.096 V with an initial accuracy of 2%. The device operates within a maximum series input voltage of 20 V and supports a maximum shunt current of 15 mA. Minimum operating current is specified at 60 uA. The component functions across a temperature range from -55 C to +125 C, featuring a temperature coefficient of 125 PPM / C.

Feature Summary

Provides a stable 4.096 V reference output via a two-terminal shunt architecture
Ensures precise voltage regulation with 2% initial accuracy tolerance
Operates reliably across extended industrial temperature ranges up to 125 C

Applications

Precision analog-to-digital converter reference sources
Data acquisition system voltage standards
Portable instrument calibration references

Procurement Notes

Verify component authenticity through authorized distribution channels due to potential counterfeit risks. Confirm RoHS compliance status against specific manufacturing lot requirements. Validate package marking alignment with official datasheet specifications prior to assembly integration. Ensure storage conditions maintain moisture sensitivity level integrity during handling procedures.

Selection Notes

Select this component when a compact SOT-23-3 footprint is required alongside moderate precision needs. The 2% accuracy suits applications tolerating wider voltage deviations compared to 1% variants. Consider thermal management capabilities given the 125 C maximum operating limit. Evaluate power supply constraints against the 20 V maximum input rating for circuit compatibility.

Part Context

This part belongs to the ZR40402 series of shunt voltage references from Diodes Incorporated. It shares architectural similarities with other members like the ZR40402F50TA but differs in output voltage specification. The series targets cost-sensitive designs requiring reliable reference performance without complex external compensation networks.
