ZVBP-2400-S+

Overview

The Mini-Circuits ZVBP-2400-S+ is a cavity bandpass filter designed for radio frequency applications. It operates within a passband of 2375 MHz to 2425 MHz, centered at 2400 MHz. The component maintains a characteristic impedance of 50 Ohms and features SMA connectors for interface connectivity. This model provides high selectivity with bandwidths as narrow as 1% and ensures an excellent low noise floor.

Feature Summary

• High selectivity performance
• Excellent low noise floor
• Narrow bandwidth capability

Applications

• WiFi laboratory testing
• Industrial RF signal conditioning
• Microwave component integration

Procurement Notes

Verify the specific part number suffix against official Mini-Circuits documentation to ensure correct connector type and tolerance specifications. Confirm that the SMA interfaces match system requirements. Cross-reference the 2375-2425 MHz range with application needs to prevent mismatch errors during procurement.

Selection Notes

Select this component when narrow bandwidth filtering near 2.4 GHz is required. The cavity design offers superior rejection characteristics compared to standard planar filters. Ensure the 50 Ohm impedance aligns with the surrounding circuit topology to minimize signal reflection and maintain optimal power transfer efficiency.

Part Context

This unit belongs to the ZVBP series of cavity bandpass filters from Mini-Circuits. These components are engineered for robust performance in RF and microwave environments. The series is known for providing stable filtering solutions across various industrial and communication applications requiring precise frequency selection.

Replacement Considerations

The ZVBP-2450-S+ serves as a related variant covering the 2400-2500 MHz range. Verify frequency alignment before substitution. No other direct substitutes are confirmed in public documentation.
