Product Detailed Parameters
- Description：CARD EDGE CONN
- Series：-
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Card Type：-
- Gender：-
- Number of Positions/Bay/Row：-
- Number of Positions：-
- Card Thickness：-
- Number of Rows：-
- Pitch：-
- Read Out：-
- Features：-
- Mounting Type：-
- Termination：-
- Contact Material：-
- Contact Finish：-
- Contact Finish Thickness：-
- Contact Type：-
- Color：-
- Flange Feature：-
- Operating Temperature：-
Download product information
Overview
The Amphenol ICC (FCI) part number 10128302-002LF is a card edge connector designed for dual-sided edge board applications. It features a female contact configuration with 40 positions arranged in two rows. The connector utilizes a through-hole termination method and includes a board lock mechanism for secure installation. Rated current is specified at 9 A, with an insulation resistance of 500 MOhms. The housing is constructed from thermoplastic material and is black in color. Contact surfaces are finished with gold or GXT™ plating over copper alloy substrates to ensure reliable signal transmission.
Feature Summary
- Dual-sided card edge interface with female contacts
- Integrated board lock mechanism for secure mounting
- Through-hole termination for PCB integration
- Gold or GXT™ plated copper alloy contacts
Applications
- High-density electronic interconnect systems
- Industrial control board connections
- Telecommunications equipment backplanes
- Data processing hardware interfaces
Procurement Notes
Verify the specific contact plating variant (standard gold versus GXT™) against project requirements, as both are documented for this series. Confirm that the 9 A current rating aligns with thermal management capabilities within the target assembly. Ensure the through-hole footprint matches the PCB design guidelines provided in the official datasheet. Validate that the board lock feature is compatible with the mechanical constraints of the enclosure.
Selection Notes
Select this component when a dual-sided card edge solution with integrated locking is required. The 40-position layout supports high pin count applications. Consider the thermoplastic housing material for general environmental protection. The through-hole termination style dictates the manufacturing process for the host printed circuit board. Evaluate the 500 MOhms insulation resistance for appropriate dielectric performance in the operating environment.
Part Context
This component belongs to the card edge connector category manufactured by Amphenol ICC (FCI). It is distinct from the HPCE® and PwrBlade® series also produced by the manufacturer. The part number 10128302-002LF specifically denotes a dual-sided female connector with 40 positions. It differs from other FCI products such as the USB micro-B receptacle (10118192-0002LF) or the Minitek power header (10127721-023LF) in form factor and application domain.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing requires matching the 40-position dual-sided female specification, through-hole termination, and board lock feature.
