10142333-10003MLF

$6.52

Description：CONN PCI EXP FMALE 164POS 0.039
Series：-
Mfr：Amphenol ICC (FCI)
Package：Tray

SKU:0b7722e5703a Category: Edgeboard Connectors Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

10142333-10003MLF is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN PCI EXP FMALE 164POS 0.039. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 10142333-10003MLF

Description：CONN PCI EXP FMALE 164POS 0.039
Series：-
Mfr：Amphenol ICC (FCI)
Package：Tray
Card Type：PCI Express™
Gender：Female
Number of Positions/Bay/Row：11; 71
Number of Positions：164
Card Thickness：0.062" (1.57mm)
Number of Rows：2
Pitch：0.039" (1.00mm)
Read Out：Dual
Features：Board Guide, Locking Ramp, Pick and Place
Mounting Type：Through Hole
Termination：Solder, Staggered
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：30.0µin (0.76µm)
Contact Type：-
Color：Black
Flange Feature：-
Operating Temperature：-55°C ~ 105°C

Edgeboard Connectors datasheet and documents for 10142333-10003MLF

10142333-10003MLF

Edgeboard Connectors Overview

The Amphenol ICC (FCI) 10142333-10003MLF is a PCI Express x16 vertical card edge connector designed for through-hole mounting. It features 164 positions with a 1mm pitch and gold-plated copper alloy contacts. The component supports PCIe Gen 4 applications and utilizes a nylon housing. This specific part number is designated as obsolete, indicating that the manufacturer will discontinue production.

Edgeboard Connectors Feature Summary

Vertical card edge connector design for PCI Express x16 interfaces
Through-hole termination with staggered solder joints
Gold-plated copper alloy contacts for reliable signal integrity

Edgeboard Connectors Applications

PCIe Gen 4 expansion cards
High-speed data transmission modules
Server and workstation hardware

Edgeboard Connectors Procurement Notes

This component is officially classified as obsolete by the manufacturer. Production has ceased, and no new units are available from authorized channels. Procurement efforts should focus on verifying existing stock availability or identifying approved replacement alternatives to ensure long-term supply chain stability.

Edgeboard Connectors Selection Notes

Engineers requiring this interface must account for the discontinued status during the design phase. Alternative connectors within the same family offering similar electrical characteristics and mechanical dimensions should be evaluated. Compatibility with existing PCB footprints and mating cards must be verified before substitution.

Edgeboard Connectors Part Context

Amphenol FCI, now part of Amphenol ICC, specializes in high-performance interconnect solutions. This connector belongs to their PCI Express series, targeting demanding computing environments. The product line emphasizes signal integrity and durability for next-generation data center and consumer electronics applications.
