1208H-33.333G50DTSTK

Overview

The 1208H-33.333G50DTSTK is a standard crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 33.333 MHz and utilizes HCMOS output logic. The device functions with a supply voltage of 5.0V and features an enable/disable control pin for power management. It is housed in an 8-DIP package, specifically a half-size metal can configuration measuring 4 leads. This component serves as a precision clock source for digital circuits requiring stable frequency generation.

Feature Summary

• Provides precise frequency generation using HCMOS output logic
• Includes enable/disable functionality for efficient power management
• Constructed in a compact half-size metal can DIP-8 package

Applications

• Digital circuit clocking systems
• Embedded controller timing references
• General-purpose signal processing applications

Procurement Notes

Verify the specific ordering suffix to confirm the exact operating temperature range and stability specifications required for your application. Ensure that the 5.0V supply voltage aligns with your system's power architecture. Confirm the physical dimensions of the half-size DIP-8 package fit within your PCB layout constraints before finalizing procurement decisions.

Selection Notes

Select this model when a 33.333 MHz reference is needed with HCMOS compatibility. Consider the 5.0V requirement against available rail voltages. Evaluate the half-size DIP-8 footprint against space limitations. Verify if the enable/disable feature supports your system's power cycling requirements compared to always-on alternatives.

Part Context

Suzhou Hangjing Elec & Tech Co., Ltd specializes in quartz frequency control components, including oscillators and resonators. The 1208H series represents their standard crystal oscillator line, designed for reliability and precision. This manufacturer focuses on R&D and production of frequency control units for various electronic industries.

Replacement Considerations

Direct substitutes must match the 33.333 MHz frequency, 5.0V supply, HCMOS output, and 8-DIP half-size metal can package. Verify equivalent stability and temperature range specifications from alternative manufacturers to ensure functional compatibility.
