1511H-10.000J33DTSK

Overview

The 1511H-10.000J33DTSK is a surface-mount HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a nominal frequency of 10 MHz with supply voltages ranging from 1.8V to 3.3V. The device features a 4-pin SMD package and offers frequency stability of +/-10ppm at 25°C and +/-20ppm over the -40°C to +85°C operating temperature range.

Feature Summary

• Supports Enable/Disable functionality for power management
• Utilizes HCMOS output logic for digital interface compatibility
• Designed for surface mount assembly in compact electronic systems

Applications

• General-purpose digital signal processing circuits
• Communication equipment requiring stable clock references
• Consumer electronics utilizing standard voltage levels

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm pinout, tolerance, and packaging details. Ensure that the selected variant matches the required supply voltage and enable/disable control specifications for the target application design.

Selection Notes

Select this component when a 10 MHz reference with HCMOS output is required within a 1.8V to 3.3V system. Consider the +/-20ppm stability over the industrial temperature range for applications demanding moderate precision without active temperature compensation.

Part Context

This part belongs to the 1511H series of standard crystal oscillators produced by Suzhou Hangjing. The company specializes in quartz frequency control components, including crystals, filters, and oscillators, serving sectors such as automotive, networking, and consumer electronics with focus on quality management standards.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Cross-reference only with identical electrical parameters and pin configurations from authorized distributors or manufacturer updates.
