Product Detailed Parameters
- Description：1612, 24MHz, HCMOS, 3.3V ,25ppm,
- Series：1511H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR)
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：24 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：3.3V
- Frequency Stability：±25ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：-
- Size / Dimension：0.063" L x 0.047" W (1.60mm x 1.20mm)
- Height - Seated (Max)：0.011" (0.28mm)
- Supplier Device Package：-
Download product information
Overview
The 1511H-24.000K33DTSK is a standard HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 24 MHz and utilizes a 3.3V supply voltage. The component features an enable/disable control function for power management. It is housed in a compact 4-SMD surface-mount package, designed for integration into space-constrained electronic circuits requiring precise clock signals.
Feature Summary
- HCMOS output interface for digital logic compatibility
- Enable/Disable pin functionality for power optimization
- Compact 4-SMD ceramic seam seal package design
Applications
- Smartphone clock signal generation
- Tablet device timing circuits
- In-vehicle system synchronization
Procurement Notes
Verify the specific manufacturing date code and lot number upon receipt to ensure compliance with project timelines. Confirm that the received components match the 1511H-24.000K33DTSK part designation exactly. Check for physical integrity of the SMD package and solder joints before assembly. Ensure storage conditions meet manufacturer specifications to maintain quartz stability.
Selection Notes
Select this component when a 24 MHz clock source with HCMOS output levels is required. The 3.3V operating voltage must align with the target system's power domain. The enable/disable feature is suitable for applications requiring dynamic power control. The 4-SMD form factor supports automated surface-mount assembly processes.
Part Context
This model belongs to the 1511H series of quartz frequency control units produced by Suzhou Hangjing Elec & Tech Co., Ltd. Founded in 2014, the company specializes in R&D and production of precision oscillators. The series is characterized by tight stability and reliability, serving as key signal-processing components for consumer electronics and communication devices.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Cross-referencing requires matching electrical parameters such as 24 MHz frequency, 3.3V supply, HCMOS output, and 4-SMD package dimensions.
