Product Detailed Parameters
- Description：oscillator,1612, HCMOS, 24MHz,25
- Series：1511H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：24 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：1.8V ~ 3.3V
- Frequency Stability：±25ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.063" L x 0.047" W (1.60mm x 1.20mm)
- Height - Seated (Max)：0.011" (0.28mm)
- Supplier Device Package：-
Download product information
Overview
The 1511H-24.000KWVDTSK is a voltage-controlled crystal oscillator (VCXO) manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a nominal frequency of 24.000 MHz and utilizes an HCMOS output signal type. The device supports a supply voltage range of 1.8V to 3.3V and includes an enable/disable control function. It is housed in a compact 4-SMD, No Lead package, designed for surface-mount applications requiring precise frequency tuning within small form factor constraints.
Feature Summary
- Voltage-controlled operation with HCMOS output
- Integrated enable and disable functionality
- Compact 4-SMD no-lead surface mount package
Applications
- Clock generation circuits requiring frequency adjustment
- Communication systems with phase-locked loop requirements
- Portable electronic devices with limited board space
Procurement Notes
Verify the specific part number suffix against official manufacturer documentation to confirm pinout configuration and electrical tolerances. Ensure that the selected variant matches the required operating temperature range and supply voltage specifications for the target application environment before finalizing procurement orders.
Selection Notes
Select this component when a voltage-tunable reference clock is required in a minimal footprint. Consider the HCMOS output compatibility with downstream logic levels and verify that the pull range meets system jitter requirements. Evaluate the enable/disable feature necessity for power management strategies in battery-operated designs.
Part Context
This VCXO belongs to the 1511H series from Suzhou Hangjing, which focuses on pressure-controlled oscillators for computing and communication sectors. The series emphasizes tight stability and reliability in small packages, aligning with industry trends toward miniaturization in mobile and wireless networking equipment.
Replacement Considerations
Consult official substitution lists for direct replacements. Verify equivalent parameters such as pull range, load capacitance, and output drive strength when considering alternative manufacturers or updated revisions of the same series.
