1521H-25.000GWVDZSK

$0.74

Description：oscillator,2016, HCMOS, 25MHz,50
Series：1521H
Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
Package：Tape & Reel (TR),Strip

SKU:33e886e212f8 Category: Oscillators Brand: Suzhou Hangjing Elec&Tech Co.,Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：oscillator,2016, HCMOS, 25MHz,50
Series：1521H
Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
Package：Tape & Reel (TR),Strip
Base Resonator：Crystal
Type：XO (Standard)
Frequency：25 MHz
Function：Enable/Disable
Output：HCMOS
Voltage - Supply：1.8V ~ 3.3V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 125°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：-
Ratings：-
Mounting Type：Surface Mount
Package / Case：-
Size / Dimension：0.079" L x 0.063" W (2.00mm x 1.60mm)
Height - Seated (Max)：0.018" (0.45mm)
Supplier Device Package：-

Download product information

1521H-25.000GWVDZSK

Overview

The 1521H-25.000GWVDZSK is a standard crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 25 MHz and utilizes HCMOS output logic levels. The device supports an operating voltage range from 1.8V to 3.3V and includes enable/disable functionality for power management. It is housed in a compact 4-SMD, No Lead package, designed for surface-mount applications.

Feature Summary

Features HCMOS output signal compatibility
Includes enable and disable control capability
Supports wide supply voltage operation

Applications

Smartphone signal processing
Satellite communication systems
In-vehicle electronic systems

Procurement Notes

Verify the manufacturer designation as Suzhou Hangjing Elec & Tech Co., Ltd. when sourcing this component. Confirm that the specific suffix ZSK corresponds to the required packaging and tape-and-reel specifications for your assembly line. Ensure the HCMOS logic level matches your system's input requirements before procurement.

Selection Notes

Select this model when a 25 MHz clock source with HCMOS output is required. Consider the 1.8V to 3.3V voltage range for compatibility with low-power digital circuits. The enable/disable feature makes it suitable for battery-operated devices requiring power conservation. Verify the 4-SMD footprint fits your PCB layout constraints.

Part Context

This component belongs to the quartz frequency control product line of Suzhou Hangjing Elec & Tech Co., Ltd., founded in 2014. The company specializes in R&D and production of crystals and oscillators for global electronics markets. This specific part represents their standard XO series designed for consumer and industrial applications.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other 25 MHz HCMOS oscillators in the 4-SMD package only if electrical parameters match exactly.
