Product Detailed Parameters
- Description：XTAL OSC XO 32KHz 1.8V HCMOS SMD
- Series：1521H
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：32 kHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：1.8V
- Frequency Stability：±30ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：15mA
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max)：0.030" (0.75mm)
Download product information
Overview
The 1521H-32K000J18DTSTK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a nominal frequency of 32 kHz with an HCMOS output type. The device supports a supply voltage of 1.8V and offers a frequency stability of ±20ppm. It is designed for operation within a temperature range of -40°C to 85°C. The component features enable/disable functionality and is packaged in a surface-mount format.
Feature Summary
- HCMOS output interface for digital signal compatibility
- Enable/disable control functionality for power management
- Surface-mount packaging for automated assembly
Applications
- Real-time clock circuits
- Low-power embedded systems
- Portable electronic devices
Procurement Notes
Verify the specific suffix codes against official manufacturer documentation to ensure correct voltage, stability, and package specifications. Confirm that the HCMOS output level matches the target circuit requirements. Check for any regional distribution restrictions or authenticity verification protocols required by Suzhou Hangjing Elec & Tech Co., Ltd. before finalizing procurement orders.
Selection Notes
Select this component when a 32 kHz reference signal is required for timekeeping or synchronization in low-voltage applications. Ensure the system design accommodates the 1.8V supply constraint and the specified ±20ppm stability tolerance. Verify that the operating temperature range meets the environmental conditions of the intended deployment scenario.
Part Context
This oscillator belongs to the 1521H series from Suzhou Hangjing Elec & Tech Co., Ltd., a company specializing in quartz frequency control components. The series includes various tuning fork crystals and oscillators designed for consumer electronics and communication devices. The manufacturer emphasizes precision supply chains and rigorous testing to maintain quality standards across its product line.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source material. Cross-reference with other 32 kHz HCMOS oscillators only if electrical parameters match exactly.
