1532D-100.000K33DTSTK

Overview

The 1532D-100.000K33DTSTK is a surface-mount HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 100 MHz with a supply voltage of 3.3V. The device features a frequency stability of ±15 ppm and an operating temperature range from -40°C to +85°C. It utilizes a 6-SMD, no lead package configuration designed for automated assembly processes.

Feature Summary

• Produces a stable 100 MHz output signal using HCMOS logic levels
• Maintains frequency accuracy within ±15 ppm across the operational temperature range
• Designed for compact surface-mount integration in electronic assemblies

Applications

• High-speed digital communication interfaces
• Network equipment clocking systems
• Consumer electronics requiring precise timing signals

Procurement Notes

Verify the specific suffix codes against official manufacturer documentation to ensure compatibility with required voltage and stability specifications. Confirm that the 6-SMD package dimensions align with the target PCB footprint. Validate that the HCMOS output level matches the receiving circuitry requirements before finalizing procurement orders.

Selection Notes

Select this component when a 100 MHz reference clock is required for applications demanding ±15 ppm stability over industrial temperatures. Ensure the design supports 3.3V operation and accommodates the specified surface-mount form factor. Consider thermal management requirements consistent with the -40°C to +85°C operational limits during system integration.

Part Context

This oscillator belongs to the 1532 series produced by Suzhou Hangjing, a company specializing in quartz frequency control components since 2014. The series includes various frequencies and packages, such as the 1532C and 1532H variants. This specific model represents a standard industrial-grade solution for general-purpose timing applications.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Cross-reference with other 100 MHz HCMOS oscillators only if electrical parameters and pin configurations match exactly.
