1532H-1.000GWVDTSTK

Overview

The 1532H-1.000GWVDTSTK is a standard HCMOS crystal oscillator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. It operates at a frequency of 1 MHz and supports a supply voltage range of 1.8 V to 3.3 V. The component features an enable/disable control function for power management. It is housed in a compact 4-SMD, no-lead package designed for surface-mount applications.

Feature Summary

• Provides stable clock signals using HCMOS output interface
• Includes enable and disable functionality for efficient power control
• Designed for surface-mount integration in space-constrained electronics

Applications

• Smartphone timing circuits
• Tablet system clocks
• In-vehicle electronic systems
• GPS module synchronization

Procurement Notes

Verify the complete part number including suffixes against official manufacturer documentation to ensure correct voltage and package specifications. Confirm that the supplier provides traceability to the original manufacturer's production records. Request test reports or datasheets specific to this variant to validate performance characteristics before finalizing procurement orders.

Selection Notes

Select this component when a low-power, surface-mount clock source with digital enable control is required. Ensure the target circuit operates within the specified 1.8 V to 3.3 V range. Verify that the 4-SMD footprint matches the PCB layout constraints. Consider the 1 MHz frequency requirement for base clock generation in portable or automotive digital systems.

Part Context

This oscillator belongs to the 1532H series from Suzhou Hangjing Elec & Tech, a manufacturer specializing in quartz frequency control components. The company focuses on precision supply chains and rigorous testing to ensure low failure rates. This series targets applications requiring reliable signal processing in consumer electronics and communication devices.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing requires matching electrical parameters, package dimensions, and output logic levels with alternative manufacturers' offerings.
