1553D-500.000J25DTSK

Overview

The 1553D-500.000J25DTSK is a 500 MHz crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates within a supply voltage range of 1.8V to 3.3V and utilizes LVDS output signaling for high-speed data transmission. The component features a frequency stability of ±25ppm over the operating temperature range of -40°C to +85°C. It is housed in a compact 6-SMD, No Lead package designed for surface mount applications.

Feature Summary

• LVDS output interface for high-speed signal integrity
• Wide supply voltage compatibility from 1.8V to 3.3V
• Compact 6-SMD no-lead surface mount packaging

Applications

• High-speed digital communication systems
• Data processing equipment requiring precise timing
• Industrial control devices with space constraints

Procurement Notes

Verify the exact part number suffix against official manufacturer documentation to ensure correct output type and voltage specifications. Confirm that the LVDS output variant matches the system requirements. Check for any specific handling instructions regarding ESD sensitivity during assembly. Ensure the supplier provides traceability documents consistent with the manufacturer's quality standards.

Selection Notes

Select this component when a 500 MHz clock source with LVDS outputs is required. Consider the ±25ppm stability requirement against system jitter tolerance. Evaluate the 1.8V to 3.3V operating range against available power rails. The 6-SMD package size should fit within the designated PCB footprint constraints.

Part Context

This model belongs to the 1553D series of standard crystal oscillators produced by Suzhou Hangjing. The series offers various frequencies and output types. This specific unit provides 500 MHz performance. The manufacturer specializes in quartz frequency controlling units established in 2014.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify pinout compatibility and electrical parameters before considering alternative sources. Consult the manufacturer directly for cross-reference information.
