Product Detailed Parameters
- Description：XTAL OSC XO 75MHZ HCMOS SMD
- Series：1553H4
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：75 MHz
- Function：Enable/Disable
- Output：HCMOS
- Voltage - Supply：1.8V ~ 3.3V
- Frequency Stability：±20ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 85°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：-
- Ratings：-
- Mounting Type：Surface Mount
- Package / Case：4-SMD, No Lead
- Size / Dimension：0.197" L x 0.126" W (5.00mm x 3.20mm)
- Height - Seated (Max)：0.047" (1.20mm)
- Supplier Device Package：-
Download product information
Overview
The 1553H4-75000GWVDTSTK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 75 MHz and utilizes HCMOS output logic levels. The device is housed in a surface-mount package with dimensions of 5032, indicating a 5.0mm x 3.2mm footprint. It supports a supply voltage range of 1.8V to 3.3V, providing flexibility for various digital circuit interfaces. This component is designed for stable clock signal generation in electronic systems requiring precise timing.
Feature Summary
- Generates a stable 75 MHz clock signal using HCMOS output interface
- Operates within a wide supply voltage range from 1.8V to 3.3V
- Utilizes a compact 5032 surface-mount package design
Applications
- Communications equipment
- Industrial control systems
- IT infrastructure components
Procurement Notes
Verify the specific ordering suffix and package variant against official manufacturer documentation before procurement. Ensure that the supply voltage requirements align with the target system's power rails. Confirm compliance with relevant quality management standards if required for the application environment. Cross-reference the part number with authorized distributors to ensure authenticity and traceability.
Selection Notes
Select this component when a 75 MHz clock source with HCMOS compatibility is required. Consider the 5032 package size for board space constraints. Evaluate the 1.8V to 3.3V operating range against available power supplies. Assess thermal and environmental conditions to ensure reliable operation within the specified parameters.
Part Context
Suzhou Hangjing Elec&Tech Co., Ltd. specializes in quartz frequency controlling units, including oscillators and resonators. The company focuses on research, development, and production of these components for various industries. This model represents their offering in the surface-mount oscillator segment, targeting applications needing precise frequency stability.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided data. Consult the manufacturer or authorized distributors for direct replacements or pin-compatible alternatives.
