1575D6-100000K33DTSNK

Overview

The 1575D6-100000K33DTSNK is a quartz crystal oscillator manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a frequency of 100 MHz and utilizes an LVDS output interface. The device is housed in a 7050 surface-mount package and functions with a supply voltage of 3.3V. This component is designed for high-frequency applications requiring stable signal generation within industrial and communication systems.

Feature Summary

• LVDS output interface for high-speed data transmission
• Compact 7050 surface-mount package design
• Operates on a standard 3.3V power supply

Applications

• High-speed serial communication links
• Network infrastructure equipment
• Industrial control systems

Procurement Notes

Verify the exact suffix codes against official manufacturer documentation to ensure correct voltage, load capacitance, and stability specifications. Confirm that the 7050 package dimensions align with your PCB footprint requirements. Check for RoHS compliance status if required by your manufacturing standards. Ensure the LVDS output type matches your receiver input specifications before finalizing the order.

Selection Notes

Select this component when a 100 MHz clock source with LVDS signaling is required in a 7050 form factor. The 3.3V operating voltage makes it suitable for modern digital logic families. Consider thermal management and board layout constraints associated with high-frequency oscillators. Verify that the specific model suffix corresponds to the desired stability and packaging options provided by the manufacturer.

Part Context

This part belongs to the 1575D6 series of oscillators from Suzhou Hangjing. The series is characterized by robust performance in small packages. Hangjing specializes in quartz frequency controlling units, including crystals, oscillators, and filters. The company was founded in 2014 and focuses on research and development in piezoelectric crystal technology.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's official cross-reference guides or datasheets for direct replacements. Ensure any alternative component matches the 100 MHz frequency, LVDS output, 3.3V supply, and 7050 package size.
