1761426-2

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors model 1761426-2 is a dual female card edge connector designed for surface mount installation. It features a 0.100-inch (2.54mm) centerline pitch and provides 30 positions, comprising 10 power contacts and 20 signal contacts. The connector utilizes gold plating on the contact surfaces to ensure reliable conductivity and corrosion resistance. This component belongs to the ULTRA series and is classified as a board-to-board card edge power connector.

Edgeboard Connectors Feature Summary

• Dual female configuration for secure mating with card edge interfaces
• Gold-plated contacts for enhanced signal integrity and durability
• Integrated power and signal positioning within a single assembly

Edgeboard Connectors Applications

• High-density electronic assemblies requiring mixed power and signal routing
• Industrial control systems utilizing card edge module architectures
• Telecommunications infrastructure equipment with standardized form factors

Edgeboard Connectors Procurement Notes

Verify that the specific application environment supports the thermal characteristics of surface mount card edge connectors. Confirm that the mating card edge thickness aligns with the connector's design specifications to ensure proper mechanical retention. Ensure that the PCB layout accommodates the required soldering profile for the dual female interface without compromising adjacent components.

Edgeboard Connectors Selection Notes

Select this component when a combined power and signal solution is required in a compact footprint. The 0.100-inch pitch allows for standard spacing while maintaining robust electrical connections. Consider the dual female orientation if the mating interface requires engagement from both sides or specific alignment constraints inherent to the system architecture.

Edgeboard Connectors Part Context

This part is part of the ULTRA series by TE Connectivity AMP Connectors, focusing on high-reliability interconnect solutions. It serves as a specialized variant within the broader card edge connector family, specifically engineered to handle both power distribution and data transmission simultaneously. The design prioritizes stability in demanding operational environments.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
