1766308-1

Edgeboard Connectors Overview

The 1766308-1 is a vertical male connector from the TE Connectivity AMP Connectors series. It features 44 positions, comprising 30 signal and 14 power contacts. The connector utilizes gold-plated terminals and is designed for through-hole mounting on printed circuit boards. This component belongs to the VRM (Voltage Regulator Module) category, intended for high-density power and data transmission applications in electronic systems.

Edgeboard Connectors Feature Summary

• Supports combined signal and power transmission within a single housing
• Features gold-plated contact surfaces for reliable conductivity
• Designed for vertical board-to-board or cable connections

Edgeboard Connectors Applications

• Voltage Regulator Module interconnections
• High-density server backplanes
• Telecommunications equipment power distribution

Edgeboard Connectors Procurement Notes

Verify the specific pinout configuration and mating partner compatibility before procurement. Confirm that the required current rating for the 14 power pins aligns with system design specifications. Ensure the PCB footprint matches the through-hole dimensions of this 44-position header. Cross-reference the latest datasheet for any recent mechanical revisions or material updates.

Edgeboard Connectors Selection Notes

Select this component when a mixed-signal solution is required for VRM applications. Consider the 30+14 position layout for optimized space utilization. Evaluate the gold plating thickness against environmental corrosion requirements. Compare against alternative series if higher current capacity per pin is needed beyond standard VRM loads.

Edgeboard Connectors Part Context

This part belongs to the broader TE Connectivity AMP Connectors portfolio, known for robust interconnect solutions. The VRM series specifically targets high-performance computing and networking sectors. As a male header, it mates with corresponding female receptacles to establish secure electrical pathways in dense electronic assemblies.

Edgeboard Connectors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing mating connectors before considering alternatives.
