2SA1708T-YMH-AN

Description：TRANS NPN/PNP 100V 1A 3-NMP
Series：-

SKU:a12c3a587843 Category: Bipolar Transistor Arrays Brand: onsemi

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：TRANS NPN/PNP 100V 1A 3-NMP
Series：-
Mfr：onsemi
Package：Tape & Box (TB)
Transistor Type：1 NPN, 1 PNP
Current - Collector (Ic) (Max)：1A
Voltage - Collector Emitter Breakdown (Max)：100V
Vce Saturation (Max) @ Ib, Ic：400mV @ 40mA, 400mA
Current - Collector Cutoff (Max)：100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce：140 @ 100mA, 5V
Power - Max：1W
Frequency - Transition：120MHz
Operating Temperature：-
Mounting Type：Through Hole
Package / Case：SC-71
Supplier Device Package：3-NMP
Grade：-
Qualification：-

Download product information

2SA1708T-YMH-AN

Overview

The 2SA1708T-YMH-AN is a PNP bipolar junction transistor manufactured by onsemi, utilizing FBET and MBIT processes for enhanced performance. It features a collector-emitter voltage rating of -30V and a continuous collector current capacity of -2A. The device is characterized by low saturation voltage (VCE(sat)) and fast switching speeds, making it suitable for high-voltage switching applications. Packaged in the YMH-AN format, this component integrates robust electrical characteristics within a compact surface-mount configuration.

Feature Summary

Adoption of FBET and MBIT manufacturing processes
High breakdown voltage with large current capacity
Fast switching speed capabilities
Low VCE(sat) design

Applications

High-voltage switching circuits
General-purpose PNP transistor applications
Power management modules requiring fast response

Part Context

This component belongs to the 2SA1708 series of PNP transistors produced by onsemi. The specific suffix indicates the packaging variant. The series is known for combining high voltage ratings with efficient current handling, leveraging advanced process technologies to minimize saturation losses while maintaining rapid transition times for digital and analog switching tasks.

Replacement Considerations

Verify pinout compatibility and thermal resistance requirements when substituting. Ensure the replacement part meets the -30V VCEO and -2A IC specifications. Check if the alternative package matches the YMH-AN footprint and soldering profile constraints.
