2SC4672-R

$0.25

Description：50V 500MW 350MV@1A,50MA 2A NPN S
Series：-

SKU:61d76b499c6f Category: Single Bipolar Transistors Brand: Shenzhen Slkormicro Semicon Co., Ltd.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

2SC4672-R is listed in the Single Bipolar Transistors range at ChipApex. The manufacturer field lists Shenzhen Slkormicro Semicon Co., Ltd.. Its product description is 50V 500MW 350MV@1A,50MA 2A NPN S. Review the specifications below when checking this part for your BOM.

Single Bipolar Transistors specifications for 2SC4672-R

Description：50V 500MW 350MV@1A,50MA 2A NPN S
Series：-
Mfr：Shenzhen Slkormicro Semicon Co., Ltd.
Package：Tape & Reel (TR),Cut Tape (CT)
Transistor Type：NPN
Current - Collector (Ic) (Max)：2:00 AM
Voltage - Collector Emitter Breakdown (Max)：50 V
Vce Saturation (Max) @ Ib, Ic：350mV @ 50mA, 1A
Current - Collector Cutoff (Max)：100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce：180 @ 500mA, 2V
Power - Max：500 mW
Frequency - Transition：210MHz
Operating Temperature：150°C (TJ)
Mounting Type：Surface Mount
Package / Case：TO-243AA
Supplier Device Package：SOT-89
Grade：-
Qualification：-

Single Bipolar Transistors datasheet and documents for 2SC4672-R

2SC4672-R

Single Bipolar Transistors Overview

The 2SC4672-R is an NPN silicon epitaxial planar transistor manufactured by Unisonic Technologies (UTC). It is designed for low-frequency applications, offering excellent DC current gain characteristics. The device features a typical saturation voltage of 0.1V at IC/IB=1A/50mA. Key electrical parameters include a maximum collector current of 2A, a collector-emitter breakdown voltage of 50V, and a transition frequency of 210MHz. Power dissipation is rated at 500mW. The component is housed in a SOT-89 surface-mount package.

Single Bipolar Transistors Feature Summary

NPN silicon epitaxial planar construction
Low saturation voltage typically 0.1V at specified currents
Excellent DC current gain characteristics
Suitable for low-frequency amplifier applications

Single Bipolar Transistors Applications

Low-frequency amplifier circuits
General-purpose switching applications
Audio signal processing stages

Single Bipolar Transistors Procurement Notes

Verify the manufacturer origin carefully, as the 'R' suffix often indicates UTC packaging but other vendors may use similar part numbers. Confirm the specific datasheet version matches your design requirements, particularly regarding thermal resistance and pinout compatibility. Ensure the SOT-89 footprint aligns with your PCB layout constraints before finalizing procurement.

Single Bipolar Transistors Selection Notes

Select this component when a low-voltage, medium-current NPN transistor is required for low-frequency operations. Consider the 50V rating and 2A current limit to ensure adequate headroom for your circuit's peak demands. The SOT-89 package offers a balance between power handling and compact surface-mount integration compared to larger through-hole alternatives.

Single Bipolar Transistors Part Context

The 2SC4672 series belongs to a family of general-purpose NPN transistors widely used in consumer electronics and industrial control systems. The UTC variant specifically targets cost-sensitive designs requiring reliable low-frequency performance. Similar parts from other manufacturers may share the base 2SC4672 designation but can vary significantly in packaging and exact electrical tolerances.
