306-006-521-104

Edgeboard Connectors Overview

The EDAC Inc. 306-006-521-104 is a standard card edge connector designed for dual-edge mating applications. It features a 12-position configuration with a 0.156-inch (3.96 mm) contact spacing. The component utilizes gold-plated copper alloy contacts housed in a green thermoplastic body. It supports a nominal printed circuit board thickness of 0.062 inches (1.57 mm). The connector is rated for 5 A current and operates within a temperature range of -40°C to +105°C, offering an insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

• Dual-edge female connector design for secure board insertion
• Gold-plated copper alloy contacts ensure reliable conductivity
• Green thermoplastic insulator body provides structural stability

Edgeboard Connectors Applications

• Industrial control systems requiring panel-mounted interfaces
• Communication equipment utilizing standard card edge modules
• Consumer electronics with modular expansion capabilities

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against the manufacturer's official datasheet to confirm exact pin count, plating specifications, and housing color. Ensure compatibility with the target PCB thickness of 0.062 inches. Cross-reference the part number with authorized distributors to confirm current availability status and regional distribution restrictions before finalizing procurement plans.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge connection is required for a 12-position interface. Confirm that the operating environment stays within the specified -40°C to +105°C thermal limits. Verify that the mating card edge thickness matches the 0.062-inch nominal requirement. Ensure the application does not exceed the 5 A current rating per contact.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series is characterized by a 0.156-inch centerline spacing and is widely used in general-purpose electronic assemblies. The 306 series offers various position counts and mounting styles to accommodate diverse board layout requirements.

Edgeboard Connectors Replacement Considerations

Consult the official EDAC cross-reference documentation for verified substitute part numbers. Do not assume functional equivalence based on similar physical dimensions alone. Verify that any alternative component meets the same electrical ratings and mechanical tolerances.
