306-008-500-108

$8.29

Description：CONN EDGE DUAL FMALE 16POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk

SKU:453673232e7f Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

306-008-500-108 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 16POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 306-008-500-108

Description：CONN EDGE DUAL FMALE 16POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：8
Number of Positions：16
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount
Termination：Solder Eyelet(s)
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Flush Mount, Top Opening, Threaded Insert, 4-40
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 306-008-500-108

306-008-500-108

Edgeboard Connectors Overview

The EDAC 306-008-500-108 is a standard card edge connector receptacle featuring eight positions with a 3.96 mm pitch. It utilizes gold-plated copper alloy contacts and a thermoplastic polyester housing. Designed for panel mount installation, this vertical connector supports a 1.57 mm board thickness and offers a 5 A current rating.

Edgeboard Connectors Feature Summary

Dual-edge contact design for secure card insertion
Gold-plated copper alloy contacts ensure reliable conductivity
Thermoplastic polyester housing provides structural stability

Edgeboard Connectors Applications

Computing and storage interconnects
Medical device circuitry
Industrial control systems

Edgeboard Connectors Procurement Notes

Verify the specific suffix code to confirm contact finish thickness and plating specifications. Ensure the selected variant matches the required panel mounting style and vertical orientation. Confirm compatibility with the target PCB edge thickness before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge card interface with a 3.96 mm pitch is required. The vertical panel mount style suits applications needing direct chassis integration. Verify that the 5 A current rating meets the system's electrical load requirements.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series provides various position counts and mounting styles for diverse electronic applications. EDAC specializes in high-reliability interconnect solutions for global OEMs.
