306-021-420-101

$10.48

Description：CONN EDGE DUAL FMALE 42POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk

SKU:f764c6a02359 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN EDGE DUAL FMALE 42POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：21
Number of Positions：42
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Tin
Contact Finish Thickness：-
Contact Type：Cantilever
Color：Green
Flange Feature：-
Operating Temperature：-40°C ~ 105°C

Download product information

306-021-420-101

Overview

The EDAC Inc. 306-021-420-101 is a standard card edge connector receptacle featuring 42 positions arranged in a dual configuration with a 0.156-inch (3.96 mm) contact spacing. Designed for vertical panel mount installation, it utilizes gold-plated copper alloy contacts and solder pin termination. The unit accommodates printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm) and employs a thermoplastic polyester insulator body.

Feature Summary

Accepts PCBs with a nominal thickness of 0.062 inches
Features a low-profile insulator body design
Utilizes single centreline row contact arrangement

Applications

Vertical panel mounting applications
Standard card edge interconnection systems
Electrical connections for specified thickness PCBs

Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required flange features and termination styles. Confirm that the selected variant matches the intended board thickness and contact spacing requirements for the target assembly.

Selection Notes

Select this component when a dual-row card edge connector with 0.156-inch spacing is required. Ensure the application supports vertical panel mounting and utilizes PCBs compatible with the 0.062-inch nominal thickness specification.

Part Context

This part belongs to the EDAC 306 series of edgeboard connectors. The series is characterized by standard card edge interface capabilities and robust construction suitable for various industrial electronic interconnection needs.

Replacement Considerations

Cross-reference with other 306-series variants such as 306-021-420-102 or 306-021-420-108 if different termination or flange configurations are needed while maintaining identical position counts and spacing.
