Edgeboard Connectors Overview

The EDAC Inc. model 316-040-520-112 is a dual-edge female connector designed for backplane applications. It features 40 positions with a single edge configuration and gold plating on the contacts. The connector utilizes a pitch of 0.125 inches (3.18mm) and is housed in a black casing. This component belongs to the Edgeboard Connectors category, providing reliable electrical interconnection for high-density mounting scenarios.

Edgeboard Connectors Feature Summary

• Dual-edge female contact configuration for secure board insertion
• Gold-plated contacts ensure durable signal transmission
• Single edge design facilitates precise alignment during assembly

Edgeboard Connectors Applications

• Backplane interconnection systems
• High-density electronic module mounting
• Edgeboard connector assemblies

Edgeboard Connectors Procurement Notes

Verify the specific part number against official EDAC documentation to confirm compatibility with mating edgeboards. Ensure that the required gold plating thickness and pitch specifications align with your system design requirements before finalizing procurement decisions.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge female interface is required for backplane architectures. Consider the 0.125-inch pitch and single-edge geometry to match existing mechanical constraints. Confirm material and plating specifications meet environmental and performance standards.

Edgeboard Connectors Part Context

This connector is part of EDAC's broader portfolio of interconnect solutions. It serves as a specialized interface within the Edgeboard Connectors subcategory, addressing needs for robust and aligned connections in complex electronic assemblies where standard pin headers are insufficient.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Consult EDAC technical support for potential cross-references or updated series replacements.
