392-033-541-112

Edgeboard Connectors Overview

The EDAC Inc. 392-033-541-112 is a single-row card edge connector from the 392 series, designed for edgeboard applications. It features 33 positions with a 0.100-inch (2.54mm) contact spacing. The connector utilizes female contacts made of copper alloy with gold plating and employs a cantilever contact type. It supports PCB thicknesses ranging from 0.054 to 0.070 inches (1.37mm to 1.78mm). The unit is constructed with a black thermoplastic polyester insulator and offers a flat mounting profile with side openings.

Edgeboard Connectors Feature Summary

• Single-edge female configuration with cantilever contact design
• Gold-plated copper alloy terminals for reliable signal transmission
• Flat mounting style with side openings for secure installation

Edgeboard Connectors Applications

• Edgeboard interconnection systems
• Standard card edge connector assemblies
• Electronic module interface connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to ensure correct contact length and termination style. Confirm that the required PCB thickness falls within the specified operational range of 0.054 to 0.070 inches. Cross-reference the part number with current manufacturer datasheets to validate availability and technical specifications prior to procurement.

Edgeboard Connectors Selection Notes

Select this component when a single-row, 33-position connection is required with 0.100-inch spacing. Ensure the application environment remains within the -40°C to +105°C operating temperature range. Verify compatibility with the target PCB material and thickness constraints before integration into the final assembly design.

Edgeboard Connectors Part Context

This component belongs to the EDAC 392 Series, which provides standard card edge connectors with 0.100-inch spacing. The series includes various position counts and termination options, catering to diverse electronic interconnection needs while maintaining consistent mechanical and electrical performance standards across the product line.

Edgeboard Connectors Replacement Considerations

Direct substitutes may include other EDAC 392 series variants with matching pin counts and spacing. Verify mechanical dimensions and terminal configurations before substitution to ensure proper fit and function in existing designs.
